AC20 75V CNC 3Nm 57mm NEMA23 Hybrid servo Closed loop stepping motor font b drive b
Нажмите чтобы посмотреть больше
AC20 75V CNC 3Nm 57mm NEMA23 Hybrid servo Closed loop stepping motor drive kit 2phase

AC20-75V CNC 3Nm 57mm NEMA23 Hybrid servo Closed loop stepping motor drive kit 2phase

60 % покупателям нравится этот товар!
Наличие: товар в наличие
45 days Money back Возврат денег в течении 45 дней Возврат принимается, если товар не соответствует описанию, покупатель оплачивает обратную доставку; или оставляете себе после обсуждения с продавцом.
On-time Delivery Доставка вовремя
Гарантии: доставка в течении 60 дней

Поделиться:

AC20-75V CNC 3Nm 57mm NEMA23 Hybrid servo Closed loop stepping motor drive kit 2phase

Package:

1. motor LC57H2100

2. drive LCDA86H

3. cable

Motor:LC57H2100

Step accuracy

5%

Temperature

80 centigrade degree Max

Ambient temperature

-20 -+50 centigrade degree

Insulation resistance

100MΩ Min 500VDC

Withstand voltage

500V AC 1minute

Shaftaxialplay

max0.06mm(450g load)

Shaft radial play

max0.08mm(450g load)

Specification:

Type

Stepping angle

Machine Length

Holding torque

Electri-city

Resis

-tance

Induc

-tance

Rotor inertia

Diameter of axle

°

mm

N.M

A

Ω

MH

g.cm2

mm

LC364

1.2

40.5

0.45

5.2

0.242

0.22

100

6.35

LC366

1.2

53.5

0.9

5.6

0.24

0.267

220

6.35

LC368

1.2

76.4

1.5

5.8

0.29

0.39

380

8.0

LC3610

1.2

102

2.0

5.8

0.376

0.5

530

8.0

Above only for the representative products, can product according to customer\’s requirements .

Drive:LCDA86H

Description:

LCDA86Hadoptingthe latest special motor controllingDSP chip and vector closed-loop control technology, thoroughly overcome the problem of the open-loop step motor losingstep, at the same time significantly improved thehigh speed performanceofmotor , reduce fever and to decrease the vibration of machine, improve processing speed and accuracyofmachine , reduce the energy consumption of machine.whenmotorbecomeoverload,the drive will output alarm signals in time, have the same reliabilityas acservo system.
Themounting dimensionofLCDA86H adaptation motor is fully compatible with86stepper motor series,convenienttoupgrade the conventional stepping driving scheme,butonly costs half of the ac servo system

Application:

It is suitable for laser processing equipment, engraving equipment, medical equipment, measurement equipment, electronic processing equipment, textile equipment, etc. Especially suitable for short distance, rapid start-up and zero speed for a short period of time stop applications.

functional characteristics

Can drive bedplate 86 of closed-loop stepper motor lichuan supporting

Voltage range: AC20-75V maximum peak current: 7A

Segmentation scope: 200 ~ 51200 ppr

Signal input: difference/single-ended, pulse/direction

Optical isolation signal inputting, strong anti-jamming capability

Impulse response frequency: 200 KHZ

Electricity parameter automatic setting function

Closed-loop vector control, high speed and large torque output of motor, meanwhile guarantee no step to lose

Variable current control, motor fever greatly reduced

Low vibration noise Over-voltage, over-current, tracking error overproof function

Small size, save installation space
